Pillar Type Threading Machines

Name: Pillar Type Threading Machines
Brand: Rising Global Machinery & Tools
Price: 325000 INR
Availability: InStock

Price 325000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Pillar Type Threading Machines Specification

Features
Sturdy pillar frame, Change gears for thread pitch, Adjustable die head

Frame Type
Pillar Type

Machine Type
Mechanical Threading

Power Rating
1.5 kW

Accuracy
0.05 mm

Lubricating System
Centralized Manual

Control System
Manual Controls

Noise Level
<75 dB

Cooling System
Flood Coolant System Provided

Frequency
50 Hz

Motor Power
1.5 HP

Product Type
Pillar Type Threading Machine

Technology
Mechanical Gear Drive

Power Source
Electric

Pressure
Standard Shop Air (if required for clamping)

Surface Treatment
Paint Coated / Powder Coated

Dimension (L*W*H)
Approx. 800 x 600 x 1400 mm

Weight (kg)
230 kg (Approx)

Color
Industrial Green / Custom

Finishing
Corrosion Resistant Coating

Operator Panel
Simple Lever and Switch Operation

Installation Type
Free Standing

Minimum Thread Diameter
6 mm

Chuck Size
110 mm

Included Accessories
Die Head, Set of Chasers, Coolant System, Electricals

Maximum Thread Diameter
40 mm

Thread Length Capacity
Up to 180 mm

Input Phase
Single / Three Phase Option Available

Safety Features
Overload Protector, Enclosed Drive

Spindle Bore
52 mm

Thread Types
Metric, BSP, UNC, UNF, NPT (Interchangeable)

Table Height From Floor
900 mm

Pillar Type Threading Machines Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cheque

Supply Ability
Unit

Delivery Time
Week

Packaging Details
As per Requirement

Main Export Market(s)
Australia, Eastern Europe, Middle East, South America, Western Europe, Africa, Central America, Asia, North America

Main Domestic Market
All India

About Pillar Type Threading Machines

Our clients can avail from us a comprehensive range of Pillar Type Threading Machines at reasonable prices. These sophisticated equipment, available in varied specifications, are assured of precise dimension and greater resilience power. They are extensively used for cutting external thread on pipes by chasing method. These hi tech threading machines, fabricated using high quality raw materials, are tested in compliance to industry quality standards for ensuring better results.

Features :

Corrosion resistant
Produces no noise and vibration
Consumes less space

Versatile Threading Capabilities

Designed for adaptability, the Pillar Type Threading Machine offers the flexibility to switch effortlessly between multiple thread types, such as Metric, BSP, UNC, UNF, and NPT. Its adjustable die head enables precise threading for both small and large diameters, making it suitable for a wide range of industrial requirements. The machines robust gear drive mechanism ensures consistent results with reliable accuracy.

Enhanced Safety and Operator Comfort

This machine prioritizes operator safety with an overload protector and an enclosed drive system. The user-friendly control panel features simple levers and switches for straightforward operation. With a table height of 900 mm, ergonomic access is provided, and a noise level below 75 dB ensures a comfortable working environment.

Comprehensive Accessory Support

Supplied with essential accessoriesincluding die head, chasers, a flood coolant system, centralized manual lubrication, and all necessary electricalsthe machine is ready for immediate installation. Its powder or paint-coated finish offers corrosion resistance, while the option for customized color supports branding or shop aesthetics.

FAQs of Pillar Type Threading Machines:

Q: How do I change between different thread types on this threading machine?

A: Switching between thread types such as Metric, BSP, UNC, UNF, or NPT is straightforward. The machine includes interchangeable die heads and a set of change gears, allowing you to select the appropriate configuration for the desired thread form. Follow the provided manual for specific adjustment steps to ensure correct installation.

Q: What is the maximum and minimum thread diameter this machine can handle?

A: This Pillar Type Threading Machine can process thread diameters ranging from a minimum of 6 mm up to a maximum of 40 mm, accommodating most common threading needs for pipes and rods.

Q: When should I use shop air pressure with this machine?

A: Shop air pressure is only required if you opt for pneumatic clamping accessories. For standard threading operations, the machine operates solely on electric power, making compressed air optional unless specified for particular clamping tasks.

Q: Where can this machine be installed?

A: With its free-standing pillar design and compact dimensions (approx. 800 x 600 x 1400 mm), the machine can be conveniently placed on any level workshop floor with access to single or three phase electric power supply. Its corrosion-resistant coating allows installation in diverse industrial environments.

Q: What maintenance is required for optimal performance?

A: Regular maintenance involves checking and refilling the centralized manual lubrication system, monitoring the flood coolant system, and ensuring all gears and chasers are clean and properly aligned. Always follow the maintenance guidelines specified in the manual to maintain accuracy (0.05 mm) and prolong machine life.

Q: How does the machine ensure operator safety during use?

A: Safety features include an overload protection system to prevent damage from excessive loads and an enclosed drive mechanism that shields moving parts. The control panel is designed for intuitive manual use, minimizing operational hazards.

Q: What are the main benefits of choosing this pillar type threading machine?

A: Key benefits include its multi-thread compatibility, high threading accuracy, sturdy construction, integrated coolant and lubrication systems, and ergonomic controls. The machines adjustable features and comprehensive accessory kit provide both versatility and convenience for industrial threading operations.
